Dual Mixer by Black Noise
Dual mixer is a dual Averager.
Each on of the 3 inputs have a gain of 1/3 of the output.
Unlike Unity gain mixer, Averager avoid clipping, so it's particularly suitable for rapidly mixing audio sources such as oscillators.
It can also be use as a precision attenuator/mixer.
Files:
Specs:
Module Depth
20mm (skiff friendly)
Power Consumption
+12V : 6mA
-12V : 8mA
+5V : 0mA
Size: 2hp
