A-RYTH-MATIK by Modulove ( DIY ) - 6 Channel Sequencer / Euclidean Rhythm Generator
Full DIY kit!
A-RYTH-MATIK is a 6-channel Eurorack gate/trigger sequencer and Euclidean rhythm generator based on Arduino-based 6-channel Eurorack with OLED-SSD1306.
The module comes as a beginner-friendly DIY kit with all SMD parts pre-soldered.
It is based on the Hagiwo Sequencer project and offers support for the added hardware reset input and LED indicators for each of the 6 channels and the clock.
Additionally, all sockets are protected against overvoltage and negative currents.
– Pre-soldered SMD parts: perfect DIY project for beginners
– Eurorack standard 3U 6HP size
– Skiff friendly
– Current: ~65mA (12V)
– Display: 128 * 64 pixels 0.96 inch
– Rotary encoder with push button
– TRIG IN: external clock input
– RESET: Reset trigger input
– Eurorack power cable included
SMD Kit
You get the pre-soldered SMD PCB and the front panel. You would then have to take care of the appropriate microcontroller and the other components (potentiometer, OLED, jacks, etc.) by yourself.
If you check the BOM that you can find on the module page and realize that you already have all the components with you, then this is an option for you.
Complete Kit
You get ALL components, as well as microcontroller, SMD-PCB, display and the front panel. Euclidean firmware is pre-flashed.
